Disposable Biopsy Instrument
Key Features:
- Core Needle is manufactured with highest quality standard for consistent core samples with left distortion of the cellular pattern.
- Minimal Tissue Displacement due to high action speed.
- Cutting Cannula shears tissue sharply, capturing quality samples in needle notch.
- Curved Needle Tip is grit-blasted to create more diffuse surface area.
- Dual Firing option for individual preference and/or patient position.
- Colour Coded Buttons for easy and accurate needle gauge identification.
Innovative Design • Precise • Cost Effective
Innovative Handle Design
Handle design is smart & functional. It is light weight for easier manipulation during procedure, provided with ribs for improved control & non-roll properties when not in use.
Instrument design is new & simpler, improved for ease of biopsy procedure with exceptional control. It offers ease of operation & enhanced control for one handed cocking. Upper slide withdraws and locks the needle cannula. The bottom slide engages and cocks the stylet.
| Product Code | Guage Size | Colour Sample | Needle Length | Length of Notch | Penetration Depth |
|---|---|---|---|---|---|
| 301.J0001A | 14 G | Green | 10.0CM | 18.0 mm | 22mm |
| 301.J0001C | 14 G | Green | 16.0CM | 18.0 mm | 22mm |
| 301.J0002A | 16 G | Purple | 10.0CM | 18.0 mm | 22mm |
| 301.J0002C | 16 G | Purple | 16.0CM | 18.0 mm | 22mm |
| 301.J0003A | 18 G | Pink | 10.0CM | 18.0 mm | 22mm |
| 301.J0003C | 18 G | Pink | 16.0CM | 18.0 mm | 22mm |
| 301.J0003D | 18 G | Pink | 20.0CM | 18.0 mm | 22mm |
| 301.J0003E | 18 G | Pink | 25.0CM | 18.0 mm | 22mm |
